Insulated Midspan Sleeves

INSULATED MIDSPAN SLEEVES / JUNCTION SLEEVES FOR V &AB CABLES

Insulated Midspan joint or Sleeves are made out of Aluminum Sleeve with VU Black Thermoplastic and rubber gland, confirming to NFC standard. Also, steel sleeves joints are available on request.

PRODUCT DETAILS

Product Code                  Specification                        PRODUCT SPECIFICATION (RANGE)

CC-IMSJ.AL16P                      NFC-033-021                           16 SQ MM- FOR PHASE CONDUCTORS -100MM

CC-IMSJ.AL25P                      NFC-033-021                           25 SQ MM MID SPAIN JOINT -100 MM FOR PHASE CONDUCTORS

CC-IMSJ.AL35P                      NFC-033-021                           35 SQ MM MID SPAIN JOINT -100 MM FOR PHASE CONDUCTORS

CC-IMSJ.AL50P                      NFC-033-021                           50 SQ MM MID SPAIN JOINT -100 MM FOR PHASE CONDUCTORS

CC-IMSJ.AL70P                      NFC-033-021                           70 SQ MM MID SPAIN JOINT -100 MM FOR PHASE CONDUCTORS

CC-IMSJ.AL95P                      NFC-033-021                           95 SQ MM MID SPAIN JOINT -150 MM FOR PHASE CONDUCTORS

CC-IMSJ.AL120P                    NFC-033-021                           120 SQ MM MID SPAIN JOINT -150 MM FOR PHASE CONDUCTORS

CC-IMSJ.AL150P                    NFC-033-021                           150 SQ MM MID SPAIN JOINT -150 MM FOR PHASE CONDUCTORS

CC-IMSJ.AL25N                     NFC-033-021                           16 SQ MM MID SPAIN JOINT (100MM) FOR NEUTRAL MESSENGAR

CC-IMSJ.AL35N                    NFC-033-021                            25 SQ MM MID SPAIN JOINT (100MM) FOR NEUTRAL MESSENGAR

CC-IMSJ.AL50N                    NFC-033-021                           35 SQ MM MID SPAIN JOINT (100MM) FOR NEUTRAL MESSENGAR

CC-IMSJ.AL54.6N                NFC-033-021                            50 SQ MM MID SPAIN JOINT (150MM) FOR NEUTRAL MESSENGAR

CC-IMSJ.AL70N                   NFC-033-021                            70 SQ MM MID SPAIN JOINT (150MM) FOR NEUTRAL MESSENGAR

CC-IMSJ.AL95NP                 NFC-033-021                            95 SQ MM MID SPAIN JOINT (200MM) FOR NEUTRAL MESSENGAR

CC-IMSJ.AL120N                 NFC-033-021                            120 SQ MM MID SPAIN JOINT (200MM) FOR NEUTRAL MESSENGAR
